Casement

Casement
SYSTEM

01. EON

Sash Details
Height max in mm 1500
Width Max in mm 750
Weight in KG 100
Sash Dimensions
Face Width in mm 67
Bottom in mm 45
Corner Joint
Sash 45 Deg
Frame 45 Deg
Glass Range
SGU 5 to 8 mm
DGU upto 24 mm
Frame Face
In mm 45
View Product Information
Locking Type
Single Yes
Multipoint upto 4 Points
Handle
Mortise Yes
Others
Wind Load upto 2 Kpa
Air tightness 600 Pa
Water tightness 600 Pa
Colour options All RAL Shades
Mesh Options Yes
Top Hung Yes
Bottom Hung Yes
Pivot No
Friction Stay Yes
Hinge Yes
Actuator Option Yes
Anti Fall Shutter device as option Yes

02. EON GRANDE

Sash Details
Height max in mm 2100
Width Max in mm 1000
Weight in KG 120
Sash Dimensions
Face Width in mm 90
Door Bottom Face Width in mm 146
Frame Face
In mm 45
Corner Joint
Sash 45 deg / At bottom 90 deg
Frame 45 deg
Glass Range
SGU 4 to 8 mm
DGU upto 24 mm
View Product Information
Locking Type
Single Yes
Multipoint upto 4 Points
Handle
Mortise Yes
Others
Wind Load upto 2 Kpa
Air tightness 600 Pa
Water tightness 600 Pa
Colour options All RAL Shades
Mesh Options Yes
Top Hung x
Bottom Hung x
Pivot x
Friction Stay x
Hinge Yes
Actuator Option x
Anti Fall Shutter device as option x

03. AXEN

Sash Details
Height max in mm 3000
Width Max in mm 1200
Weight in KG 200
Sash Dimensions
Face Width in mm 92
Door Bottom Face Width in mm 100
Frame Face
In mm 73
Corner Joint
Sash 45 deg / At bottom 90 deg
Frame 45 Deg
Glass Range
SGU 5 to 12 mm
DGU upto 38 mm
View Product Information
Locking Type
Single Yes
Multipoint upto 4 Points
Handle
Mortise Yes
Others
Wind Load upto 2 Kpa
Air tightness 600 Pa
Water tightness 600 Pa
Colour options All RAL Shades
Mesh Options Yes
Top Hung xxx
Bottom Hung xxx
Pivot xxx
Friction Stay xxx
Hinge Yes
Actuator Option xxx
Anti Fall Shutter device as option xxx
