Sliding

Sliding
SYSTEM

01. ZENITH

  • Ideal for Standard home Opening with smooth & Easy Openings
  • Supports basic glass thickness & offers good daily -use performance
  • Slim Interlock keeps the design neat without compromising function
  • Best suited for budget friendly residential applications
Sash Details
Max Height (mm) 2000
Max Width (mm) 900
Weight (kg) 90
Interlock Visibilty
Non Slim (mm) 66
Slim (mm) 20
Track Options & Depth
2 track (mm) 70
3 track (mm) 97
Handle
Concealed Yes
Mortise No
View Product Information
Corner Joint
Sash 45 deg
Track 45 deg
Glass Range
SGU 5 to 8 mm
DGU upto 20 mm
Locking Type
Single Yes
Multipoint upto 2 Points
Others
Wind Load upto 2 Kpa
Air tightness 250 Pa
Water tightness 250 Pa
Colour options All RAL Shades
Mesh Options Yes

02. VANTA

  • Offers higher height & width capability for larger window spans
  • Better wind, air & Water performances for enhanced comfort
  • Compatible with thicker glass for improved insulation and sound control
  • A balanced choice between performance, durabilty & aesthetics.
Sash Details
Max Height (mm) 2400
Max Width (mm) 1200
Weight (kg) 120
Interlock Visibilty
Non Slim (mm) 65
Slim in mm 25
Track Options & Depth
2 track (mm) 65
3 track (mm) 101
Handle
Concealed Yes
Mortise Yes
View Product Information
Corner Joint
Sash 45 deg / 90 deg for sleek interlock
Track 45 deg
Glass Range
SGU 5 to 8 mm
DGU upto 20 mm
Locking Type
Single Yes
Multipoint upto 4 Points
Others
Wind Load upto 2.5 Kpa
Air tightness 300 Pa
Water tightness 300 Pa
Colour options All RAL Shades
Mesh Options Yes

03. GRANDEUR

  • Designed for large,tall openings with maximum strength & stability
  • Handles heavier sash weight and ensures premium sliding smoothness
  • Superior performance in wind, air and water sealing for bigger and taller windows
  • Ideal for Architectural requirements
Sash Details
Max Height (mm) 3600
Max Width (mm) 1500
Weight (kg) 200
Interlock Visibilty
Non Slim (mm) 92
Slim (mm) 25
Track Options & Depth
2 track (mm) 90
3 track (mm) 140
Handle
Concealed Yes
Mortise Yes
View Product Information
Corner Joint
Sash 45 deg / 90 deg for sleek interlock
Track 45 deg
Glass Range
SGU 5 to 10 mm
DGU upto 24 mm
Locking Type
Single Yes
Multipoint Upto 4 Points
Others
Wind Load 3 Kpa
Air tightness 400 Pa
Water tightness 400 Pa
Colour options All RAL Shades
Mesh Options Yes

FORGE 32
Coming Soon

KURO
Coming Soon
