Sash Details
Height max in mm
3000
Width Max in mm
1200
Weight in KG
200
Sash Dimensions
Face Width in mm
92
Door Bottom Face Width in mm
100
Frame Face
In mm
73
Corner Joint
Sash
45 deg / At bottom 90 deg
Frame
45 Deg
Glass Range
SGU
5 to 12 mm
DGU
upto 38 mm
Locking Type
Single
Yes
Multipoint
upto 4 Points
Handle
Mortise
Yes
Others
Wind Load
upto 2 Kpa
Air tightness
600 Pa
Water tightness
600 Pa
Colour options
All RAL Shades
Mesh Options
Yes
Top Hung
xxx
Bottom Hung
xxx
Pivot
xxx
Friction Stay
xxx
Hinge
Yes
Actuator Option
xxx
Anti Fall Shutter device as option
xxx
