Sash Details
Height max in mm
1500
Width Max in mm
750
Weight in KG
100
Sash Dimensions
Face Width in mm
67
Bottom in mm
45
Corner Joint
Sash
45 Deg
Frame
45 Deg
Glass Range
SGU
5 to 8 mm
DGU
upto 24 mm
Frame Face
In mm
45
Locking Type
Single
Yes
Multipoint
upto 4 Points
Handle
Mortise
Yes
Others
Wind Load
upto 2 Kpa
Air tightness
600 Pa
Water tightness
600 Pa
Colour options
All RAL Shades
Mesh Options
Yes
Top Hung
Yes
Bottom Hung
Yes
Pivot
No
Friction Stay
Yes
Hinge
Yes
Actuator Option
Yes
Anti Fall Shutter device as option
Yes
