Sash Details
Height max in mm
2100
Width Max in mm
1000
Weight in KG
120
Sash Dimensions
Face Width in mm
90
Door Bottom Face Width in mm
146
Frame Face
In mm
45
Corner Joint
Sash
45 deg / At bottom 90 deg
Frame
45 deg
Glass Range
SGU
4 to 8 mm
DGU
upto 24 mm
Locking Type
Single
Yes
Multipoint
upto 4 Points
Handle
Mortise
Yes
Others
Wind Load
upto 2 Kpa
Air tightness
600 Pa
Water tightness
600 Pa
Colour options
All RAL Shades
Mesh Options
Yes
Top Hung
x
Bottom Hung
x
Pivot
x
Friction Stay
x
Hinge
Yes
Actuator Option
x
Anti Fall Shutter device as option
x
