- Ideal for Standard home Opening with smooth & Easy Openings
- Supports basic glass thickness & offers good daily -use performance
- Slim Interlock keeps the design neat without compromising function
- Best suited for budget friendly residential applications
Sash Details
Max Height (mm)
2000
Max Width (mm)
900
Weight (kg)
90
Interlock Visibilty
Non Slim (mm)
66
Slim (mm)
20
Track Options & Depth
2 track (mm)
70
3 track (mm)
97
Handle
Concealed
Yes
Mortise
No
Corner Joint
Sash
45 deg
Track
45 deg
Glass Range
SGU
5 to 8 mm
DGU
upto 20 mm
Locking Type
Single
Yes
Multipoint
upto 2 Points
Others
Wind Load
upto 2 Kpa
Air tightness
250 Pa
Water tightness
250 Pa
Colour options
All RAL Shades
Mesh Options
Yes
